DDRC1220FR-GL-V3 | 12 x 20A Relays Controller (feed through) General Loading

The Dynalite DDRC1220FR-GL is a 12-channel relay controller designed for switching a wide range of loads in a Dynalite control system. It is a practical choice when you need reliable on/off control for lighting circuits, power circuits, contactors, gates, exhaust fans, pumps, signage, or other switched services.

Installed on DIN rail in the distribution board, the DDRC1220FR-GL gives you twelve individually controllable relay channels in a compact format. It can operate as part of a wider DyNet-based control system, or be used in applications where switching needs to respond to wall switches, sensors, timers, logic, or automation events.

This makes it especially useful in projects where not every load is dimmed. For example, a site may use DALI, phase dimming, or other output types for some circuits, while the relay controller handles simple switched loads, non-lighting outputs, or trigger-based control. It is also a strong option for extensions to existing Dynalite systems where additional switched circuits need to be added cleanly within the same control platform.

With front-panel override switching, diagnostic capability, and support for common wiring arrangements, the DDRC1220FR-GL is well suited to commercial, residential, and mixed-use projects that need robust switched load control with the flexibility of Dynalite integration.
